Saj Sununo 5kw Single Phase Inverter
₨ 150,000
SAJ Sununo 5kW Single Phase On-Grid Inverter (Sununo TL5k) with dual MPPT, IP65 protection, 97.7% peak efficiency, and WiFi/Ethernet monitoring. Compact, fan-less design ensures long-term durability and reliable solar energy conversion.
The SAJ Sununo 5kW Single Phase On-Grid Inverter (Sununo TL5k) is a powerful and reliable solar inverter designed for residential and small commercial solar systems. With a PV capacity of 5200W, two independent MPPT trackers, and a 97.7% peak efficiency, it maximizes energy generation even under varying solar conditions.
Its transformerless, fan-less design enhances durability while reducing maintenance costs. The IP65 protection rating ensures safe outdoor installation in diverse climates. For smart monitoring, it supports RS485 (standard) and optional WiFi/Ethernet connectivity, along with an integrated web server for local and online performance tracking.
This inverter is optimized for flexibility, safety, and long-term performance, making it an excellent choice for modern solar installations.
Key Features:
- Rated Power: 5kW Single Phase On-Grid Inverter
- Model: Sununo TL5k
- PV Capacity: 5200W
- Two Independent MPPT Trackers (parallel support)
- IP65 protection – suitable for outdoor installation
- 97.7% peak efficiency with optimized MPPT at low power
- Transformerless, compact, fan-less design
- Datalogger & Communication: 2×RS485 (Standard), WiFi/Ethernet (Optional)
- Integrated Web Server & SAJ Web Portal Monitoring
- LCD (16×2 with backlight) & LED indicators
Specification |
Details |
|---|---|
| Model Name | Sununo TL5k |
| Rated Power | 5kW Single Phase On-Grid |
| PV Capacity | 5200W |
| Maximum AC Current | 25A |
| MPPT Voltage Range | 120 – 440 VDC |
| IP Protection | IP65 |
| Operating Temperature | -25°C to +60°C |
| Net Weight | 26 kg |
| Dimensions (W×H×D) | 525 × 425 × 190 mm |
| Number of MPPTs | 2 (parallel support) |
| Communication | 2×RS485 (Standard), WiFi/Ethernet (Optional) |
| Display | LCD (16×2, backlight) & LED (3 lights) |
| Efficiency (Peak) | 97.7% |
