Saj Sununo 5kw Single Phase Inverter

Saj Sununo 5kw Single Phase Inverter

 150,000

Features:

  • Two independent MPPT trackers for Flexible configuration.
  • Super junction MOSFET integrated with 97.7% Max. efficiency.
  • Optimized MPPT efficiency even for very low power.
  • Transformerless design for lower cost and compact size.
  • IP65 and fan-less for longer-term reliability.
  • Ethernet/ Wi-Fi communication interface.
  • Integrated Web Server for local and internet monitoring.
  • Support SAJ Web Portal Monitoring Solutions.

Specification

Details

Model Name Sununo TL5k
PV Capacity 5200W
IP Protection IP 65
Maximum AC Current 25Amp
MPPT Voltage Range 120 VDC~ 440 VDC
Operating Temperature -25°C to +60°C
Net Weight 26 kg
Dimensions (W × H × D) 525 × 425 × 190 mm
Number Of MPPT Trackers 2 (can parallel)
Datalogger & Communication 2×RS485 (Standard), WiFi/Ethernet (Optional)
LCD Display LCD (16×2 Characters, Backlight) & LED (3 Lights)
Efficiency (Peak) 97.7%
