Inverex Nitrox 10KW – 48V Hybrid Solar inverter (Single phase) PV 16000W

Inverex Nitrox 10KW – 48V Hybrid Solar inverter (Single phase) PV 16000W

 499,000

SKU AR-002283 Category

NITROX HYBRID 10KW SP-5G Solar Inverter

The NITROX HYBRID 10KW SP-5G is a high-performance hybrid solar inverter featuring advanced MPPT technology and smart energy management. It supports both lithium-ion and lead-acid batteries and can handle a maximum PV input power of 16,000W. Designed for both off-grid and on-grid applications, this inverter is an excellent choice for residential and industrial use.

Key Features

  • Hybrid Solar Inverter – Supports both grid-tied and off-grid functionality for flexible power solutions.
  • High PV Input Power (16,000W) – Ensures maximum solar energy utilization with high power capacity.
  • Advanced MPPT Technology – Delivers over 99% efficiency for optimal solar power tracking.
  • Battery Compatibility – Works with both lead-acid and lithium-ion batteries.
  • Smart Monitoring & Control – Supports GPRS, WIFI, Bluetooth, and 4G connectivity for remote monitoring.
  • Surge Protection & Safety – TYPE II DC and AC surge protection for enhanced system security.
  • IP65 Protection Rating – Durable design suitable for outdoor and harsh environments.
  • Intelligent Cooling System – Efficient air cooling mechanism for optimal performance.
  • High Efficiency (97.6%) – Maximizes energy conversion while minimizing losses.
  • Multiple Communication Interfaces – Supports RS485, RS232, and CAN bus for seamless integration.

The NITROX HYBRID 10KW SP-5G is a reliable and smart energy solution, ideal for homes, offices, and industrial setups. Its hybrid design and high efficiency ensure energy independence and cost savings.

NITROX HYBRID 10KW SP-5G Specifications

Category Specifications
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range (V) 40-60
Max. Charging Current (A) 210
Max. Discharging Current (A) 210
Charging Strategy for Li-ion Battery Self-adaption to BMS
Number of Battery Input 1
Max. PV Input Power (W) 16000
Max. PV Input Voltage (V) 500
Start-up Voltage (V) 125
MPPT Voltage Range (V) 150-425
Rated PV Input Voltage (V) 370
Max. Operating PV Input Current (A) 32+32
Max. Input Short-Circuit Current (A) 48+48
Rated AC Input/output Active Power (W) 10000
Max. AC Input/output Apparent Power (VA) 11000
Rated AC Input/output Current (A) 50/47.9
Max. AC Input/output Current (A) 45.5/43.5
Max. Continuous AC Passthrough (grid to load) (A) 32+32
Peak Power (off-grid) (W) 2 times of rated power, 10s
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Max. Efficiency 97.6%
Euro Efficiency 96.5%
MPPT Efficiency >99%
Total Current Harmonic Distortion (THDi) <3% (of nominal power)
DC Injection Current <0.5% In
Surge Protection Level TYPE II (DC), TYPE II (AC)
Grid Regulation IEC 61727, IEC 62116, CEI 0-21, EN 50549, etc.
Operating Temperature (°C) -40 to +60, >45°C derating
Permissible Ambient Humidity 0-100%
Permissible Altitude 2000m
Noise (dB) <30
Ingress Protection (IP) Rating IP 65
Inverter Topology Non-Isolated
Over Voltage Category OVC II (DC), OVC III (AC)
Cabinet Size (W x H x D mm) 343×580×258 (Excluding Connectors and Brackets)
Cooling Type Intelligent Air Cooling
Weight (kg) 25.2
Warranty 5 Years (depends on installation site)
Monitor Mode GPRS/WIFI/Bluetooth/4G/LAN (optional)
Communication Interface RS485/RS232/CAN
Grid Connection Form L+N+PE
Rated Input/output Voltage/Range (V) 220/230 (0.85Un-1.1Un)
Rated Input/output Grid Frequency/Range (Hz) 50/45-55, 60/55-65
